Automatic Thermal Film Laminaion Machine Model Beta

Get a Price/Quote

Automatic Thermal Film Laminaion Machine Model Beta Specification

Max Film Width
760 mm

Max Lamination Temp
150C

Membrance Core Size
1 inch / 3 inch

Lamination Speed
Up to 30 meters per minute

Material
Mild Steel Body with Aluminum Components

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Control Panel with Touch Screen

Drive Type
Electric Motor Drive

Heating System
Infrared Heating System

Power Source
AC Electric

Voltage
220V / 380V, 50Hz

Weight (kg)
500 kg (approx.)

Dimension (L*W*H)
2200 mm x 1200 mm x 1500 mm

Capacity
Up to 1800 sheets/hour

Color
Blue & White

Input Paper Size
Max: 20 x 30 (508 mm x 762 mm)

Suitable Paper
80 gsm to 500 gsm

About Automatic Thermal Film Laminaion Machine Model Beta

Automatic Thermal Film Lamination Machine Model Beta

Features

Single side sheets to sheet thermal lamination
Films matta and gloss BOPP
Integrated feeder which can take stock from 120-450 gsm
Pneumatically controlled Nip pressure roller and inline cutting unit
The roll of film is mounted on quick change air shaft with film tension controlled by a pneumatic brake.
Film roll has a trim slitter and perforating mechanism.
The separated sheets are properly collected on a Motorized jogger
Entire process of feeding, laminating and inline cutting as per increasing speed level are synchronized and ensures non - stop laminating.

Advanced Lamination Efficiency

Designed for superior productivity, the Model Beta streamlines the lamination process with automation and precise control. Operators benefit from a touch screen PLC panel, electric motor drive, and reliable infrared heating, ensuring high speed and uniform quality for every sheet. With its solid build and modern features, this machine is tailored for demanding print finishing operations.

Versatile Paper Handling

This machine supports a wide variety of paper types and thicknesses, from 80 gsm to 500 gsm. Its large input tray allows sheets up to 20" x 30" in size, and it handles different film widths up to 760 mm. Whether your needs are small or large-scale, the Model Beta adapts to various lamination tasks effortlessly.

User-Friendly Automation

The Model Beta is engineered for operator convenience. The PLC control panel with touch screen interface streamlines setup and monitoring. Automated processes reduce manual intervention, while safety features ensure smooth and secure operation, making it ideal for continuous usage in industrial settings.

FAQs of Automatic Thermal Film Laminaion Machine Model Beta:

Q: How does the Automatic Thermal Film Lamination Machine Model Beta operate?

A: The Model Beta runs on a fully automatic system controlled by a PLC panel with a touch screen. Simply set the required parameters, load your sheets, and the machine takes care of lamination using its electric motor drive and infrared heating. It is designed for continuous, efficient, and user-friendly operation.

Q: What types of paper and film are compatible with this lamination machine?

A: This machine accommodates paper weights from 80 gsm to 500 gsm and handles sheets up to 20 x 30. It is compatible with film rolls possessing a core size of either 1 inch or 3 inches and a maximum width of 760 mm.

Q: When should I use the Model Beta for my laminating needs?

A: The Model Beta is ideal when you require high-speed, large-scale, and high-quality lamination. It suits print shops, packaging companies, and manufacturers who need to laminate documents, brochures, or packaging material efficiently.

Q: Where can this machine be installed and used?

A: Due to its robust build and industrial capacity, the Model Beta is suitable for installation in factories, print finishing units, or dedicated lamination workshops across India and worldwide. It operates efficiently on standard 220V/380V, 50Hz power supplies.

Q: What is the lamination process like with the Model Beta?

A: Operators load the input sheets, select settings on the touch screen, and the infrared heating system activates to bond the film onto the paper. The PLC automation ensures precise temperature, speed, and alignment throughout the process for consistent, quality results.

Q: How does the machine improve productivity and efficiency?

A: With a lamination speed of up to 30 meters per minute and a capacity for 1800 sheets per hour, the Model Beta significantly enhances output. The automation reduces manual labor, minimizes errors, and shortens production cycles, leading to greater overall efficiency.

Q: What benefits does the Model Beta offer to exporters, manufacturers, and suppliers?

A: This model caters to demanding commercial needs by providing reliable, high-volume lamination. Its robust construction, user-friendly controls, and adaptability to various paper sizes ensure durable and professional finishes, boosting the appeal and longevity of printed products.
