Board Pasting Machines

Board Pasting Machines
Board Pasting Machines
Product Code : 20
Product Description

With firm commitment to quality, we are engaged in manufacturing and exporting an extensive gamut of Board Pasting Machines. These machines are widely used for the pasting operations of different card boards, papers and sheets by using water-based glue which is adjusted according to the several materials. These machines are engineered with precision with the help of superior quality materials that are obtained from authorized vendors of the market. These Board Pasting Machines can be availed from us at competitive prices.

Features:



  • High functionality
  • Excellent performance
  • Corrosion resistant property

Further Details:

Board Pasting Machines

Our Board Pasting Machines are distinguished by their universality of application and highly accurate registration levels of ± 0.5mm. The machine can handle cardboard, pasteboard, Corrugated Sheets etc. With perfect registration. The Machine works with water-based glue that can be adjusted to suit different materials. The accuracy is obtained because the top and bottom sheets are controlled by combination of photocell and mechanical cotrols that ensure neat and perfect alignment prior to lamination.

Specifications

Model

DAYA 800

DAYA 1100

Maximum Sheet Size (W)

800 mm

1100 mm

Maximum Sheet Size (L) 1000 mm 1400 mm

Minimum Sheet Size (W)

200 mm

200 mm

Minimum Sheet Size (L)

350 mm

350 mm

Top Sheet Thickness

130 to 450 gsm

130 to 450 gsm

Minimum Bottom Sheet Laminating

250 gsm to 10 mm

250 gsm to 10 mm

Speed Drive

1200 Sheet/Hr

1200 Sheet/Hr

Drive

3 + 2 H.P. DC variable drive

5 + 2 H.P. DC variable drive

Air Compressor 6 Bar:80 PSI:34 CFM 6 Bar:80 PSI:34 CFM

Voltage

440/3/50

440/3/50

Pressing Unit
9 feet long compression section

  • Depends upon the properties of materials being used and existing operating conditions
  • Larger sizes custom built machine available on request.
